PTDD series Silent Mixed-Flow Inline Duct Fans provide efficient
cooling with a low profile outer design that results in quiet
operation.
Each fan includes two-layer sound absorption material and
uniquely positioned sound wave holes that reduce unwanted
noise. The double diameter sealed connection is leak-proof and
shock resistant.
PTDD series fans also include three-speed operation (low,
medium, high) a timer, temperature sensor, and humidity sensor.
The fans can operate from -20℃ to 60℃ and also include dual
ball bearings for long-life operation up to 50,000 hours.
Protection Class:IP44.
Unit of Measure

Specifications

Speed

 N/A H

Voltage

 N/A 220 to 240 V

Frequency

 N/A 50 Hz

Current

 N/A 0.57 A

Power

 N/A 128 Watts

Speed

 N/A 2450 rpm

Airflow

 N/A 494 cfm840 m³/h

Pressure

 N/A 1.41 inH2O35.81 mmAq350.86 Pa

Noise

 N/A 35 dBA

Weight

 N/A 5.9 kg

Dimensions

A

 N/A 13.35 in339 mm

B

 N/A 5.04 in128 mm

C

 N/A 4-5.6

D

 N/A 7.80 in198 mm

E

 N/A 17.17 in436 mm

L

 N/A 22.32 in567 mm

W

 N/A 10.32 in262 mm

H

 N/A 11.85 in301 mm

Dimensional Drawing

<span data-measure='general'><img src="/Asset/PTDD_dim.jpg"></img><br/>PTDD SERIES - Silent Mixed-Flow Inline Duct Fans_dim<br/></span>

Applications

Applications

 N/A HVAC
Fresh Air Systems
Air Purification
Communication Equipment
