Catalog
12V, 24V
19.7~31 CFM (0.56~0.88 m3/min)
Ball Bearings
Lead Wires: UL1007 (+) Red; (-) Black, AWG 22/24
Operating Temperature: -40ºC ~ +65ºC
Operating Life: 10,000 hours at 25ºC
Tachometer (Frequency Generator)
PWM Speed Control
RoHS
19.7~31 CFM (0.56~0.88 m3/min)
Ball Bearings
Lead Wires: UL1007 (+) Red; (-) Black, AWG 22/24
Operating Temperature: -40ºC ~ +65ºC
Operating Life: 10,000 hours at 25ºC
Tachometer (Frequency Generator)
PWM Speed Control
RoHS
Unit of Measure
Specifications
Voltage |
N/A 24 V |
Range |
N/A 18 to 26.5 V |
Current |
N/A 0.75 A |
Power |
N/A 18.0 Watts |
Speed |
N/A 14000 rpm |
Airflow (Q) |
N/A 30.9 cfm0.88 m³/h |
Pressure (P) |
N/A 6.03 inH2O153.2 mmAq |
Noise |
N/A 68.6 dBA |
