Catalog
5V, 24V
15.2~37.0 CFM (0.43~1.05 m3/min)
Ball Bearings
Lead Wires: UL1007 (+) Red; (-) Black, AWG 24
Operating Temperature: -40ºC ~ +65ºC
Operating Life: 10,000 hours at 25ºC
Tachometer (Frequency Generator)
PWM Speed Control
RoHS
15.2~37.0 CFM (0.43~1.05 m3/min)
Ball Bearings
Lead Wires: UL1007 (+) Red; (-) Black, AWG 24
Operating Temperature: -40ºC ~ +65ºC
Operating Life: 10,000 hours at 25ºC
Tachometer (Frequency Generator)
PWM Speed Control
RoHS
Unit of Measure
Specifications
Voltage |
N/A 24 V |
Range |
N/A 18 to 26.5 V |
Current |
N/A 1.55 A |
Power |
N/A 37.2 Watts |
Speed |
N/A 20000 rpm |
Airflow (Q) |
N/A 37.05 cfm1.049 m³/h |
Pressure (P) |
N/A 9.56 inH2O271.09 mmAq |
Noise |
N/A 74.0 dBA |
