PTF-P series Mixed-Flow Inline Duct Fans are well suited for
indoor exhaust fresh air systems, ventilation, and
humidification.
Mixed-Flow technology delivers a high flow rate in a small space
against a high back pressure and provides a low power and low
noise solution that can be used in almost any high-density
cooling application.
Each fan is designed with a special integrated housing with
innovative joints for easy installation and maintenance. The fan
housing is made of high endurance and lightweight PP material.
The fans can operate from -20℃ to 60℃ and also includes dual
ball bearings for long-life operation up to 50,000 hours.
Protection Class:IP44.
Unit of Measure

Specifications

Speed

 N/A L

Voltage

 N/A 220 to 240 V

Frequency

 N/A 50 Hz

Current

 N/A 0.52 A

Power

 N/A 123 Watts

Speed

 N/A 1950 rpm

Airflow

 N/A 406 cfm690 m³/h

Pressure

 N/A 1.1 inH2O27.94 mmAq273.72 Pa

Noise

 N/A 55 dBA

Weight

 N/A 4.0 kg

Dimensions

A

 N/A 3.94 in100 mm

B

 N/A 3.70 in94 mm

C

 N/A 4- ø5.5

D

 N/A 7.76 in197 mm

E

 N/A 4.92 in125 mm

F

 N/A 5.39 in137 mm

G

 N/A 8.07 in205 mm

L

 N/A 11.89 in302 mm

W

 N/A 9.80 in249 mm

H

 N/A 9.33 in237 mm

Dimensional Drawing

<span data-measure='general'><img src="/Asset/PTF-P_dim.jpg"></img><br/>PTF-P SERIES - Mixed-Flow Inline Duct Fans_dim<br/></span>

Applications

Applications

 N/A HVAC
Fresh Air Systems
Air Purification
Communication Equipment
